PIAGGIO Beverly 300 i.e. - Taillight Assy.; Footrest

Taillight assy.
To remove the rear light assembly, proceed as fol-
lows:
- Remove the side fairings;
- Undo the three screws indicated in the figure.
See also
Side fairings
Footrest
The following procedure is applicable for both
sides of the vehicle:
- Unscrew the three screws indicated and remove
the passenger footrest;
- Unscrew the screw fastening the footrest to the
side fairing;
Chassis Beverly 300 i.e.
CHAS - 262
