PIAGGIO Beverly 300 i.e. - Shock Absorbers Removal; Shock Absorbers Refitting; Exhaust Bracket Removal

Removal
Proceed as follows:
- place the vehicle on its centre stand;
- lift the engine a little with a jack so as to free the
two shock absorbers;
- remove the silencer
- undo the shock absorber spring assembly clamp-
ing screw from the support fixed to the engine on
the one side and from that fixed to the silencer on
the other;
- unscrew the two upper nuts (one on each side)
fixing the shock absorber spring assembly to the
frame and remove the shock absorbers.
See also
Exhaust assy. Removal
Refitting
Carry out the previous operations but in reverse order.
Locking torques (N*m)
Left shock absorber lower retainer 33 ÷ 41 Right shock absorber lower retainer 40 ÷ 45 Upper
shock absorber retainer 40 ÷ 45
Exhaust bracket
Removal
- Remove the silencer;
- Disconnect the connector from the speed sensor;
Beverly 300 i.e. Suspensions
SUSP - 227
