PIAGGIO Beverly 300 i.e. - Inspecting the Hub Cover

Characteristic
Connection diameter for countershaft:
A = Ø 15 - 0.01 -0.02 mm
Connection diameter for wheel shaft:
B = Ø 25 - 0.020 -0.035 mm
C = diameter 15 - 0.01 -0.02 mm
Bearing diameter for driven pulley shaft:
D = Ø 15 - 0.01 -0.02 mm
E = 19.8 ± 0.1
F = Ø 20 - 0.01 -0.02 mm
Inspecting the hub cover
- Check that the fitting surface is not dented or distorted.
- Check the bearing bearings.
- In case of faults, replace the damaged components.
Beverly 300 i.e. Engine
ENG - 127
