4.F04-15A
5.Starter switch
6.F05-10A
7.F06-5A
10.12V - 10Ah Battery
11.Chassis ground
23.Rear right turn indicator
24.Rear left turn indicator
25.Front right turn indicator
26.Front left turn indicator
27.Antitheft
28.Turn indicator warning light
29.Turn indicator switch
30. turn indicator control
31.Low beam light bulb
32.High beam light bulb
33.High beam warning light
34.Light switch
35.Headlight solenoid
36.Electronic control unit
46.Starter button
47.Right stop light bulb
48.Left stop light bulb
49.Stop button
50.Stop button
51.License plate lighting bulb
54.Rear right turn indicator bulb
55.Rear left turn indicator bulb
56.Front right turn indicator bulb
57.Front left turn indicator bulb
Checks and inspections
This section is dedicated to the checks on the electrical system components.
Immobiliser
The electronic ignition system is controlled by the control unit with the integrated Immobilizer system.
The immobilizer is an anti-theft system that allows the vehicle to be operated only when it is started with
coded keys recognised by the control unit. The code is integrated in a transponder in the key block.
Beverly 300 i.e. Electrical system
ELE SYS - 75
