PIAGGIO Beverly 300 i.e. - Rear Handlebar Cover

- Unscrew the centre screw and retrieve the wash-
ers;
- Remove the luggage rack.
Rear handlebar cover
To remove the handlebar cover, proceed as fol-
lows:
- Remove the mirrors unscrewing them from their
seats
- Unscrew the two screws «A» and remove the
pressure covering.
- Unscrew the two screws «B» and, working on
both sides of the vehicle, unscrew the screw «C».
- Using a flat-headed screwdriver, detach the fas-
tener tab as shown in the figure, accessing the tab
via the indicated slit
- Insert the screwdriver between the two covers,
as indicated in the figure, and detach the upper
fastener tab
- Move the rear handlebar cover aside, disconnect
all the electrical connectors and remove the han-
dlebar cover.
Beverly 300 i.e. Chassis
CHAS - 253
