Code Action Duration
3 003001 Handlebar - Replacement
4 003061 Accelerator transmission - adjust
5 002063 Complete throttle transmission - Re-
placement
6 002071 Left knob - Replacement
7 002037 Brake lever - Replacement
8 002067 Rear brake pump - Replacement
9 002024 Front brake pump - Replacement
10 004162 Mirror mounting and/or brake pump
fitting U-bolt - Replacement
11 004066 Driving mirror - Replacement
Swing-arm
SWINGING ARM
Code
Action Duration
1 003080 Swinging arm on frame - Replace-
ment
2 001072 Engine/chassis swinging arm attach-
ment - Replacement
3 004058 Silent block - Replacement
4 003081 Swinging arm support flange - Re-
placement
Time Beverly 300 i.e.
TIME - 318
