N.B.
THE ARROW STAMPED ON THE DISC INDICATING THE RUNNING DIRECTION MUST BE FITTED
TOWARDS THE OUTSIDE OF THE VEHICLE.
Recommended products
Loctite 243 Medium-strength threadlock
Medium Loctite 243 threadlock
Locking torques (N*m)
Brake disc screws 8 ÷ 10
Disc Inspection
Checking the disc is important; it must be perfectly
clean, with no sign of rust, oil or grease or any oth-
er dirt, and must show no signs of deep scoring.
Characteristic
Thickness of a new front disc
4.0 mm
Disc thickness at wear limit (front)
3.5 mm
- Remove the wheel and check using the appro-
priate tools that the axial run-out of the brake
surface is within the prescribed limits.
- If this is not the case, replace the disc and repeat
the test.
WHEN INSTALLING, THOROUGHLY CLEAN THE DISC
AND ITS SEAT ON THE HUB.
Characteristic
Max. axial run-out
0.1 mm
Front brake pads
Braking system Beverly 300 i.e.
BRAK SYS - 238
