PIAGGIO Beverly 300 i.e. - Removing the Cylinder Head

- Remove the camshaft.
- Acting on flywheel-side holes, push and slide off
the rocking lever pins.
N.B.
IF NEEDED, THE HEAD MAY BE REMOVED WITH THE
CAMSHAFT, ROCKER PINS AND FIXING BRACKET. THE
HEAD CAN ALSO BE REMOVED WITHOUT REMOVING
THE CHAIN AND THE CRANKSHAFT CHAIN TENSIONER.
Removing the cylinder head
- Undo the two screws «1» fixing the head to the
transmission-side crankcase half.
- Unscrew the four nuts «2» by loosening them in
two or three stages and in a crossed sequence.
Engine Beverly 300 i.e.
ENG - 140
