Removal
- Remove the two retainers fastening the front
brake calliper to the support as shown in the pic-
ture.
N.B.
SHOULD IT BE NECESSARY TO REPLACE THE CALLIP-
ER, FIRST LOOSEN THE FITTING CONNECTING THE PIPE
TO THE BRAKE CALLIPER.
Refitting
- To fit the calliper, follow the above operations but in reverse order.
Locking torques (N*m)
Screw tightening calliper to support 24 ÷ 27
If the calliper is replaced:
CAUTION
ALWAYS USE NEW COPPER WASHERS.
CAUTION
ONCE REFITTING IS FINISHED, BLEED THE SYSTEM.
Locking torques (N*m)
Brake fluid pipe-calliper fitting 20 ÷ 25
See also
Front
Rear brake disc
These vehicles may feature a rear wheel with integrated hub or with a hub independent from the wheel.
Removal
REAR WHEEL WITH INTEGRATED HUB
Beverly 300 i.e. Braking system
BRAK SYS - 235
