Removing the ignition key-switch when on *lock*
In position "Lock", it is not possible to access the
cylinder retaining spring. The spring must then be
removed as shown in the figure, allowing the lock
spring to be pressed out.
N.B.
TO REFIT THIS ITEM, THE VEHICLE STEERING LOCK
MUST BE RELEASED WITH THE LOCK BODY (INTERNAL
AND EXTERNAL PART) IN POSITION "OFF". PROCEED AS
DESCRIBED IN THE PREVIOUS PARAGRAPH.
See also
Removing the ignition key-switch when on *off*
Front wheel housing
To remove the front wheel housing, proceed as
follows:
- Remove the leg shield back plate;
- Remove the handlebar covers;
- Remove the fork;
- Release the indicated clamps from the wheel
housing;
- Undo the three screws indicated and remove the
wheel housing.
See also
Knee-guard
Beverly 300 i.e. Chassis
CHAS - 261
