PIAGGIO Beverly 300 i.e. - Fuel Tank Diagram

- Unscrew the two screws indicated;
- Lift the rear of the helmet compartment, discon-
nect the helmet compartment light connector and
release the saddle release linkage retainer clip;
- Remove the helmet compartment, detaching
from the fuse terminal block.
See also
Side fairings
Fuel tank
KEY:
Beverly 300 i.e. Chassis
CHAS - 267
