WEIGHTS AND DIMENSIONS
Specification Desc./Quantity
Length 2150 mm
Width 780 mm
Wheelbase 1535 mm
Height 1190 mm
Kerb weight 171 kg ± 8 kg
Maximum weight allowed 365 kg
Engine
ENGINE
Specification Desc./Quantity
Type Single-cylinder, 4-stroke
Engine capacity 278 cm³
Bore x stroke 75 X 63 mm
Compression ratio 11 ± 0.5 : 1
Engine idle speed 1,700 ± 100 rpm
Timing system Four valves, single overhead camshaft, chain-driven.
Valve clearance Intake: 0.10 mm Exhaust: 0.15 mm
Max. power 16.3 kW at 7,250 rpm
MAX. torque 23 Nm at 5,750 rpm
Lubrication Engine lubrication with trochoidal pump (inside the crankcase),
oil filter and pressure adjustment by-pass.
Fuel system 32 MIU1.E9 Electronic injection, with Ø 32-mm throttle body
and electric fuel pump.
Cooling Forced coolant circulation system.
Fuel Unleaded petrol (95 RON)
Silencer Absorption-type exhaust muffler with catalytic converter and
lambda probe.
Emissions compliance EURO 3
Transmission
TRANSMISSION
Specification
Desc./Quantity
Transmission CVT expandable pulley variator with torque server, V-belt, self-
ventilating dry automatic centrifugal clutch and transmission
housing with forced-circulation air cooling.
Final reduction gear Gear reduction unit in oil bath.
Capacities
CAPACITY
Specification
Desc./Quantity
Engine oil 1.3 l
Transmission oil 250 cm³
Cooling system fluid 1.75 l
Fuel tank 13 l ± 1
Beverly 300 i.e. Characteristics
CHAR - 9
