- Remove by releasing the cable passages and
sliding the protection collar upwards.
Using the special tool, loosen and remove the up-
per ring nut, the spacer washer and the counter-
lock ring.
- Extract the fork.
N.B.
TAKE CARE TO SUPPORT THE FORK SO AS TO PREVENT
IT FROM COMING OFF ABRUPTLY
Specific tooling
020055Y Wrench for steering tube ring nut
Refitting
- Fit the lower steering bearing on the steering
tube.
- Fit the fork together with the lower steering bear-
ing on the headstock and hold it so that it does not
fall.
N.B.
LUBRICATE THE STEERING FIFTH WHEEL TRACKS WITH
RECOMMENDED GREASE BEFORE USE.
Recommended products
AGIP GREASE PV2 Ivory smooth-textured,
slightly-stringy anhydrous calcium-base
grease.
TL 9150 066, NATO G 460 symbol
Suspensions Beverly 300 i.e.
SUSP - 214
