PIAGGIO Beverly 300 i.e. - Front Mudguard

Front mudguard
To remove the front mudguard, proceed as fol-
lows:
- On both sides of the vehicle, unscrew the indica-
ted screws and remove the stanchion guard;
- Unscrew the three bolts indicated inside the mud-
guard;
- Detach the brake hose from the two indicated
seats and remove the mudguard, pulling from the
front.
Chassis Beverly 300 i.e.
CHAS - 276
