PIAGGIO Beverly 300 i.e. - Knee-Guard

- Open the glove compartment and undo the indi-
cated screw from both sides of the vehicle.
- Move the shield aside, releasing the fastener
clips, and disconnect the connectors and lamp
holders from the headlights;
- Unscrew the three screws indicated to remove
the two headlights from the shield.
See also
Frame central cover
Knee-guard
To remove the leg shield back plate, proceed as
follows:
- Remove the legshield;
- Unscrew the expansion tank cap;
- Unscrew the two screws indicated and release
the two retainer tabs to remove the indicated cov-
er;
- Unscrew the screw located above the emergency
saddle release lever and the screw near the igni-
tion key;
Chassis Beverly 300 i.e.
CHAS - 258
