Name Torque in Nm
Fixing screws for the handlebar control unit U-bolts 7 ÷ 10
Steering tube upper ring nut 40 to 45
Steering tube lower ring nut 14 - 17
CHASSIS
Name Torque in Nm
Centre stand bolt 40 to 45
Side stand fixing bolt 40 to 45
Refer to the table in section "Suspensions/Swinging arm/Fitting" for the tightening torques of the swinging arm.
FRONT SUSPENSION
Name Torque in Nm
Front wheel axle 45 ÷ 50
Fork leg screw 6 - 7
front mudguard to plate fixing screw 4.5 to 7
Fixing screw for mudguard plate to fork 9 - 11
Stem support clamp tightening screws 20 ÷ 25
Fork locking screws cap 15 ÷ 30
Hydraulic rod fixing screw 25 ÷ 35*
REAR SUSPENSION
Name Torque in Nm
Rear wheel axle 104 ÷ 126
Fixing screw for wheel rim to hub 34 ÷ 38
Right shock absorber lower retainer 40 ÷ 45
Left shock absorber lower retainer 33 ÷ 41
Silencer supporting arm to engine screws (*) 20 to 25
Upper shock absorber retainer 40 ÷ 45
FRONT BRAKE
Name
Torque in Nm
Brake fluid pump-hose joint 16 - 20
Oil bleed screw 12 - 16
Pad fastening pin 19.6 to 24.5
Screw tightening calliper to support 24 ÷ 27
Brake disc screws 8 ÷ 10
Brake fluid pipe-calliper fitting 20 ÷ 25
REAR BRAKE
Name
Torque in Nm
Rear brake calliper-pipe fitting 20 ÷ 25
Rigid / flexible pipe fitting 13 - 18
Rear brake pump-pipe fitting 16 - 20
Rear brake calliper fixing screws 20 to 25
Brake disc screws 8 ÷ 10
Pad fastening pin 19.6 to 24.5
MUFFLER
Name
Torque in Nm
Silencer heat guard fixing screw 4 to 5
Screw for fixing silencer to supporting arm 20 ÷ 25
Lambda probe tightening on exhaust manifold 40 - 50
Exhaust manifold-silencer joint tightening 12 to 13
Nut fixing silencer to cylinder head 16 to 18
LUBRICATION
Name
Torque in Nm
Hub oil drainage plug 15 to 17
Oil filter on crankcase fitting 27 ÷ 33
Engine oil drainage plug/ mesh filter 24 ÷ 30
Oil filter 4 ÷ 6
Beverly 300 i.e. Characteristics
CHAR - 11
