D = Low fuel warning light
E = Speedometer
F = Immobiliser LED
G = Coolant temperature gauge
H = Engine control telltale light
I = Engine oil pressure warning light
L = Digital display
Ground points
- Frame ground points «A» and «B». Remove the
left footrest to reach them.
- Engine ground point «C»
Electrical system installation
Electrical system Beverly 300 i.e.
ELE SYS - 60
