Medium Loctite 243 threadlock
Locking torques (N*m)
Pad fastening pin 19.6 to 24.5
Rear brake pads
Removal
- Remove the rear brake calliper
- Loosen the two pins shown in the figure that lock
the two pads; be careful with the pad spring clamp.
- Remove the brake pads and check there are no
faults or warping. Replace it if such anomalies are
present.
- Check the thickness of the friction material is
more than 1.5 mm. If it is not, replace it
- The replacement must be made with greater re-
sidual thickness if the brake pad has not worn
evenly. A 0.5 mm thickness difference in the re-
sidual friction material is permitted.
See also
Removal
Braking system Beverly 300 i.e.
BRAK SYS - 240
