PIAGGIO Beverly 300 i.e. - Overhaul Data; Assembly Clearances; Flywheel Data; Crankcase and Crankshaft Data

Name Torque in Nm
Oil pump cover screws 7 to 9
Screws fixing oil pump to the crankcase 5 - 6
Oil pump command crown screw 10 ÷ 14
Oil pump cover plate screws 4 ÷ 6
Oil sump screws 10 ÷ 14
Minimum oil pressure sensor 12 ÷ 14
CYLINDER HEAD
Name Torque in Nm
Spark plug 12 ÷ 14
Head cover screws 6 ÷ 7
Nuts fixing head to cylinder 7±1 + 10±1 + 270°
Head fixing side screws 11 - 12
Starter ground screw 7 ÷ 8.5
Tappet adjustment check nut 6 - 8
Intake manifold screws 11 ÷ 13
Timing chain tensioner slider screw 10 ÷ 14
Starter counterweight support screw 11 to 15
Timing chain tensioner support screw 11 ÷ 13
Timing chain tensioner central screw 5 ÷ 6
Camshaft retention plate screw 4 ÷ 6
TRANSMISSION
Name Torque in Nm
Belt support roller screw 11 ÷ 13
Clutch unit nut on driven pulley 45 ÷ 50
Drive pulley nut 75 ÷ 83
Transmission cover screws 11 ÷ 13
Driven pulley shaft nut 54 ÷ 60
Rear hub cap screws 24 ÷ 27
FLYWHEEL
Name
Torque in Nm
Flywheel cover screw 11 ÷ 13
Stator assembly screws 3 - 4 (Apply LOCTITE medium type 242 threadlock)
Flywheel nut 94 - 102
Pickup fixing screws 3 ÷ 4
Screw fixing freewheel to flywheel 13 - 15
CRANKCASE AND CRANKSHAFT
Name
Torque in Nm
Internal engine crankcase bulkhead (transmission-side half
shaft) screws
4 ÷ 6
Engine-crankcase coupling screws 11 ÷ 13
Starter motor screws 11 - 13
Crankcase timing cover screws 3.5 - 4.5 (Apply LOCTITE medium type 242 threadlock)
COOLING
Name
Torque in Nm
Water pump rotor cover 3 to 4
Screws for water pump rotor driving link 3 to 4
Thermostat cover screws 3 - 4
bleed screw: 3
Overhaul data
Assembly clearances
Characteristics Beverly 300 i.e.
CHAR - 12
