PIAGGIO Beverly 300 i.e. - Radiator Fan; Expansion Tank

Radiator fan
To remove the radiator electric fan, proceed as
follows:
- Remove the front wheel housing.
- Obtain a suitably sized container and drain the
cooling system by removing the indicated clamp.
Open the expansion tank cap to facilitate draining;
- Detach the radiator from the circuit pipes;
- Unscrew the indicated screw and remove the ra-
diator, lifting out of its seat.
See also
Front wheel housing
Expansion tank
To remove the expansion tank, proceed as fol-
lows:
- Remove the leg shield back plate;
- Drain the cooling system by removing the indi-
cated clamp;
- Unscrew the indicated screw and remove the ex-
pansion tank.
Beverly 300 i.e. Chassis
CHAS - 277
