Driven pulley
DRIVEN PULLEY
Code
Action Duration
1 001022 Clutch - Replacement
2 001012 Driven pulley - overhaul
3 001110 Driven pulley- Replacement
4 001155 Clutch housing - Replacement
Time Beverly 300 i.e.
TIME - 294
