- Lubricate the closing cap O-ring of the stem.
- Preload the spring, fit the closing cap and tighten
to the prescribed torque.
Locking torques (N*m)
Fork locking screws cap 15 ÷ 30
- Repeat the procedure for the other fork leg.
N.B.
IF BOTH FORK LEGS ARE SERVICED AT THE SAME TIME, BE CAREFUL NOT TO INVERT THE
RIGHT FORK LEG WITH THE LEFT ONE.
Steering column
Removal
- Remove the front wheel.
- Remove the front mudguard
- Remove the front brake calliper
- Remove the front and rear handlebar covers.
- Remove the pin mounting the handlebar to the
steering tube.
- Remove the handlebar and rest it on the shield
back plate.
Beverly 300 i.e. Suspensions
SUSP - 213
