PIAGGIO Beverly 300 i.e. - Page 259

- Undo the two screws indicated in the figure;
- Disconnect the LV socket connector and the
coolant return pipe from the relative seat on the leg
shield back plate;
- Unscrew the screw fastening the expansion tank
to the leg shield back plate, taking care not to spill
any coolant;
- Detach the emergency saddle release linkage
from the lever as indicated in the figure;
- Remove the leg shield back plate.
See also
Legshield
Beverly 300 i.e. Chassis
CHAS - 259
