Hook the retaining clip on the rear hole of the inner
bracket of the frame and lock the tube in corre-
spondence with the yellow marking.
Bring the valve downwards and keep it from the
inside to the crosspiece of the frame.
In this way it is ensured that the valve does not
come into contact with the electric fan and the ra-
diator.
Drain the black rubber tube towards the seat of the
horn and insert it in the support bracket of the
crosspiece fixing the footrests.
Finally, let out, toward the rear side of the vehicle,
the end part of the black rubber pipe.
CAUTION
MAKE SURE THAT ALONG THE PATH THERE ARE NO
CHOKES IN THE BREATHER PIPE.
Beverly 300 i.e. Chassis
CHAS - 275
