PIAGGIO Beverly 300 i.e. - Driving Pulley and Rollers Case Service

- Insert the adaptor sleeve of the appropriate tool
in the hole shown in the picture
- Insert the tool in the hollows and apply the reten-
tion ring
- Bring in the ring's clamping screws while keeping
the tool to support the pulley
- Remove the fixing nut and the washer
- Remove the stationary drive pulley half.
Specific tooling
020626Y008 Driving pulley lock wrench
- Remove nut «1», Belleville spring «2», and wash-
er «3».
- Remove the stationary driving half-pulley.
Engine Beverly 300 i.e.
ENG - 120
