Check function of fuses No. 3 and 6 for the ECU
and injection load solenoid.
Check the efficiency of the injection load solenoid.
Check the resistance of the energising coil be-
tween pins 86 and 85: 40 to 80 Ohm
Apply a voltage of 12V to pins 86 and 85; make
sure that there is continuity between pins 30 and
87 of the relay.
WARNING
TO INDICATE THE RELAY OF THE DESIRED FUNCTION,
REFER TO THE PIN-CABLE COLOUR RELATIONSHIP
WITH THE ATTACHED ELECTRIC SYSTEM DIAGRAM.
Beverly 300 i.e. Injection
INJEC - 181
