- Reinsert the spacer bushing on the brake disc
side using the appropriate tool and take it to the
stop.
Specific tooling
020376Y Adaptor handle
020359Y 42x47-mm Adaptor
020412Y 15-mm guide
020201Y Spacer bushing driving tube
- Turn over the wheel and insert the internal spacer
with the part fitted with the Seeger ring facing the
bearing on the brake disc side installed previously.
- Heat the bearing seat on the odometer drive side
with the heat gun.
- Insert the two bearings using the punch consist-
ing of adaptor handle, 32x35 mm adaptor and 15
mm guide, and drive it up to the stop.
Specific tooling
020376Y Adaptor handle
020357Y 32x35-mm Adaptor
020412Y 15-mm guide
