PIAGGIO Beverly 300 i.e. - Page 229

- Working from the left hand side of the vehicle,
unscrew the two screws indicated and remove the
rear mudguard;
- Remove the safety split pin, aligning with the re-
cess on the bracket. Remove the nut cap;
- Undo the nut fastening the rear wheel;
- Unscrew the two screws fastening the silencer
mounting bracket to the engine, as indicated in the
figure, and remove the bracket.
See also
Exhaust assy. Removal
Beverly 300 i.e. Suspensions
SUSP - 229
