5. Battery: lift the saddle and remove the battery
cover to access the battery.
6. Fuses: lift the saddle and remove the battery
cover to access the battery.
7. relays: lift the saddle and remove the battery
cover to access the battery.
8. Diagnostic socket: lift the saddle and remove the
battery cover to access the battery.
9. Control unit: lift the saddle and remove the en-
gine inspection cover to access the ECU.
10. Saddle actuator: to reach it, remove the left
fairing.
11. H.V. coil: remove the helmet compartment to
reach it.
Beverly 300 i.e. Electrical system
ELE SYS - 57
