Global configuration mode
【Usage】
Max Age is used to configure the longest aging interval of STP. Dropping
message when overtiming. The STP will be frequently accounts and take
crowded network to be link fault, if the value is too small. If the value is too large,
the link fault cannot be known timely. Max Age is determined by diameter of
network, and the default time of 20 seconds is suggested.
Caution：2*(Hello Time + 1) ≤ Max Age ≤ 2*( ForwardDelay – 1)
【Example】
！Configure the Max Age to 10 seconds
QTECH(config)#spanning-tree max-age 10
7.1.7 spanning-tree port-priority
Use spanning-tree port-priority command to configure the port priority of the
current port in the specified spanning tree. Use no spanning-tree port-priority
command to restore the current port to the default port priority in the specified
7-9
