Chapter 5 Maintaining Your Library
Monitoring the Library
Scalar i2000 User’s Guide 210
•The SCSI Channel Status dialog box displays information about the
SCSI connection on the MCB.
•The Fibre Channel Status dialog box displays information about the
FC connections on the MCB and the I/O blades (if any exist).
You must perform the following procedures while viewing the physical
library.
Viewing I/O Blade Status Information 5
1 Make sure that you are viewing the physical library. From the View
menu, click the name of the physical library.
2 Click Monitor→ Connectivity→ IO Blade.
The IO Blade Status dialog box appears.
The following table describes the elements on the IO Blade Status dialog
box.
If the library does not detect at least one chassis
management blade (CMB) in the library, the IO
Blade command does not appear on the menu.
Element Description
Type The type of I/O blade (“FC IOB” indicates an I/O blade).
