Chapter 5 Maintaining Your Library
Monitoring the Library
Scalar i2000 User’s Guide 211
3 From the IO Blade Status dialog box, you can perform the following
tasks:
• Change the sorting of I/O blades in the status list (for example,
by type or location) by clicking the column heading by which you
want the I/O blades sorted. Repeatedly clicking a column
heading toggles between ascending and descending order.
• Mail, save, or print status information by using the Send button
(see
Mailing, Saving, and Printing Status Information on
page 230.
Viewing SCSI Channel Status Information 5
1 Make sure that you are viewing the physical library. From the View
menu, click the name of the physical library.
2 Click Monitor→ Connectivity→ SCSI Channel.
The SCSI Channel Status dialog box appears.
Location The location of the blade (see I/O Blade Locations on page 376).
Firmware
Version
The firmware version of the blade.
Serial Number The serial number of the blade.
WWN The World Wide Name of the blade.
CC LUN The Command and Control LUN (typically, the CC LUN is mapped to
LUN
0).
Element Description
