R&S ZVB - Page 1017

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 1002
SOURce1:POWer:ALC:COUPle ON
Use identical ALC settings for all ports in channel 1.
SOURce1:POWer:ALC:RANGe 5
Select a 5 dB control range (for all ALC ports).
SOURce1:POWer1:ALC:SOFFset 0; POFFset OFF
Select a start value offset of 0 and don't use the ALC correction value of the last
measured sweep point as the start value.
SOURce1:POWer1:ALC:CLAMp OFF
Don't suspend the ALC during the measurement.
SOURce1:POWer:ALC:AUBW ON
Enable automatic bandwidth setting.
SOURce1:POWer:ALC:STOL 1
Select a 1 dB settling tolerance window.
SOURce1:POWer:ALC:LPNoise OFF
Don't activate the Low Phase Noise Mode for ALC.
SOURce<Ch>:POWer<Pt>:ALC:BANDwidth <bandwidth>
Selects the bandwidth in the ALC control loop for port <Pt> in channel <Ch>. The setting takes effect
when automatic bandwidth setting is disabled (using SOURce<Ch>:POWer<Pt>:ALC:AUBW).
<Ch>
Channel number
<Pt>
Port number
<bandwidth>
Bandwidth setting (ALC Path IF Bandwidth in ALC Config dialog not set to Auto)
Range [def. unit]
20 Hz to 7.12 MHz [Hz]. For a list of possible values refer to the Control Loop
Parameters section of the ALC Config dialog description.
*RST value
1 kHz
SCPI, Command
Types
Device-specific, command or query.
Example:
See SOURce<Ch>:POWer<Pt>:ALC:PIParameter
SOURce<Ch>:POWer<Pt>:ALC:CLAMp <Boolean>
Suspends the ALC mechanism at source port <Pt> in channel <Ch> while the analyzer acquires
measurement data (Clamp in ALC Config dialog).
<Ch>
Channel number
<Pt>
Port number
<Boolean>
ON | OFF
*RST value
OFF
SCPI, Command Types
Device-specific, command or query.
