R&S ZVB - Page 1073

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 1058
Example:
See SYSTem:COMMunicate:RDEVice:PMETer<pmeter_no>:DEFine
SYSTem:COMMunicate:RDEVice:PMETer<pmeter_no>:COUNt?
Queries the number of configured external power meters.
<pmeter_no>
Number of the configured power meter. This suffix is ignored; the command
affects all power meters.
Response
Number of power meters.
*RST values
*RST has no effect on the configured power meters.
SCPI, Command
Types
Device-specific, query only
Example:
See SYSTem:COMMunicate:RDEVice:PMETer<pmeter_no>:CATalog?
SYSTem:COMMunicate:RDEVice:PMETer<pmeter_no>:DEFine '<pmeter_name>',
'<driver>', '<interface>', '<address>'
Configures an external power meter and adds it to the list of available power meters.
<pmeter_no>
Number of the configured power meter. Power meters must be numbered in
ascending order, starting with 1. If a number is re-used, the previous power
meter configuration is overwritten.
Power meters can be assigned several times so that the number of configured
power meters is practically unlimited.
'<pmeter_name>'
Name of the external power meter (string parameter). An empty string means
that no particular name is assigned to the power meter.
'<driver>'
Power meter type (string parameter). The power meter type is identical with the
name of the power meter driver file (*.pwm) stored in the resources\extdev
subdirectory of the analyzer's program directory. Type the driver file name as
shown in the Add External Generator dialog, i.e. without the file extension
".pwm" (example: use 'NRVD', if the corresponding driver file name is
NRVD.pwm).
Alternative: The '<driver>' string may also contain the power meter driver file
name with its complete path, e.g. 'C:\Program Files\Rohde&Schwarz\Network
Analyzer\resources\extdev\nrvd.pwm'.
'<interface>'
Interface type (string parameter): 'USB' (for the supported USB devices)
'<address>'
Interface address (string parameter), depending on the interface type.
*RST values
*RST has no effect on the configured power meters.
SCPI, Command
Types
Device-specific, command or query
Example:
SYST:COMM:RDEV:PMET:CONF:AUTO OFF
Disables Auto Config NRP-Zxx (if it was enabled previously).
SYST:COMM:RDEV:PMET1:DEF 'USB Power Meter', 'NRP-Z55', 'usb', '100045'
Configure an R&S NRP power meter as external power meter no. 1, assigning
the name USB Power Meter and a serial number 100045.
