Trace Menu
Operating Manual 1145.1084.12 – 30 186
 Import Complex Data... calls up an Open File dialog to load a memory trace from a trace file.
 Export Complex Data... calls up a Save As... dialog to store data or memory traces to a trace file.
 Export S-Matrix... calls up a Save As... dialog to store a complete set of S-parameter data to a
trace file.
 Export Formatted Data... calls up a Save As... dialog to store data or memory traces with their
current trace format and stimulus values to a trace file.
Import Complex Data...
Calls up a dialog to load a memory trace from a trace file. Trace files are ASCII files with selectable file
format.
Trace data import requires complex trace values. A warning is displayed, and data import fails, if the
trace file contains real data only, e.g. a magnitude trace exported via Export Formatted Data.
