Trace Menu
Operating Manual 1145.1084.12 – 30 208
 Search Range... assigns a search range to each marker of the current trace.
The search functions are available in all Cartesian and polar diagram types (see Trace – Format). In
polar diagrams (Polar, Smith, Inverted Smith), where complex values are displayed, the magnitude of the
response values provides the search criterion.
Max Search
Sets the active marker to the absolute maximum in the search range, i.e. to the largest of all response
values. If a complex trace format (e.g. a polar diagram) is active, the marker is set to the measurement
point with the maximum magnitude.
By default the search range coincides with the sweep range. If the active trace contains no markers, a
marker M 1 is created to indicate the search result.
Remote control:
CALCulate<Chn>:MARKer<Mk>:FUNCtion:EXECute MAXimum
CALCulate<Chn>:MARKer<Mk>:FUNCtion:RESult?
Min Search
Sets the active marker to the absolute minimum in the search range, i.e. to the smallest of all response
values. If a complex trace format (e.g. a polar diagram) is active, the marker is set to the measurement
point with the minimum magnitude.
By default the search range coincides with the sweep range. If the active trace contains no markers, a
marker M 1 is created to indicate the search result.
Remote control:
CALCulate<Chn>:MARKer<Mk>:FUNCtion:EXECute MINimum
CALCulate<Chn>:MARKer<Mk>:FUNCtion:RESult?
Next Peak
Sets the active marker to the next maximum or minimum in the search range, depending on the current
search criterion.
 If a Max Search or a Bandpass Search is active, then the marker is set to the next maximum. The
next maximum is the maximum with the largest response value that is below the current marker
response value.
 If a Min Search or a Bandstop Search is active, then the marker is set to the next minimum. The
next minimum is the minimum with the smallest response value that is above the current marker
response value.
By default the search range coincides with the sweep range. If the active trace contains no markers, a
marker M 1 is created to indicate the search result. Next Peak is disabled while a Target Search is active.
Remote control:
CALCulate<Chn>:MARKer<Mk>:FUNCtion:EXECute NPEak
CALCulate<Chn>:MARKer<Mk>:FUNCtion:RESult?
