R&S ZVB - Page 664

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 649
Parameters
See list of parameters below.
*RST value
–
SCPI,
Command
Types
Device-specific, no query.
Example:
Suppose that the active setup contains an active trace no. 1.
CALC:MARK ON
Create marker 1 and assign it to trace no. 1.
CALC:MARK:FUNC:EXEC MAX; RES?
Move the created marker to the absolute maximum of the trace and query the
stimulus and response value of the search result.
The analyzer provides the following search modes:
Mode
Find...
MAXimum
Absolute maximum in the search range (see CALCulate<Chn>:MARKer<Mk>:FUNCtion:DOMain:USER
<numeric_value>)
MINimum
Absolute maximum in the search range
RPEak
Next valid peak to the right of the current marker position
LPEak
Next valid peak to the left
NPEak
Next highest or lowest value among the valid peaks (next peak)
TARGet
Target value (see CALCulate<Chn>:MARKer<Mk>:TARget)
RTARget
Next target value to the right of the current marker position
LTARget
Next target value to the left
BFILter
Bandfilter search. The results are queried using CALCulate<Chn>:MARKer<Mk>:BWIDth.
SPRogress
Sweep progress (marker tracking)
CALCulate<Chn>:MARKer<Mk>:FUNCtion:RESult?
Returns the result (stimulus and response value) of a search started by means of
CALCulate<Chn>:MARKer<Mk>:FUNCtion:EXECute. The search must be executed before the
command is enabled.
<Chn>
Channel number used to identify the active trace
<Mk>
Marker number in the range 1 to 10. This numeric suffix is ignored and may be set
to any value.
Response
The result information depends on the search mode of the preceding marker
search.
In case a bandfilter search was executed, the marker number is ignored and the
query returns the following list of values:
<bandwidth>,
<Center freq>,
<Lower Band Edge Stimulus>,
