R&S ZVB - Page 665

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 650
<Lower Band Edge Response>,
<Extreme Stimulus>,
<Extreme Response>,
<Upper Band Edge Stimulus>,
<Upper Band Edge Response>
For all other search modes the marker number identifies a particular marker of the
active trace and the query returns the value pair <stimulus>, <response>.
Range [def.
unit]
Depending on the measurement parameter. [unit depending on the sweep type and
the marker format; see CALCulate<Chn>:MARKer<Mk>:FORMat]
*RST value
–
SCPI,
Command
Types
Device-specific, query only
Example:
See CALCulate<Chn>:MARKer<Mk>:FUNCtion:EXECute.
CALCulate<Chn>:MARKer<Mk>:FUNCtion[:SELect] MAXimum | MINimum | RPEak
| LPEak | NPEak | TARGet | LTARget | RTARget | BFILter | SPRogress
[Deprecated command]
Selects a search mode for marker no. <Mk>, which can then be initiated using one of the
CALCulate<Chn>:MARKer<Mk>:SEARch..., CALCulate<Chn>:MARKer<Mk>:MAXimum or
CALCulate<Chn>:MARKer<Mk>:MINimum functions. The marker must be created before using
CALCulate<Chn>:MARKer<Mk>[:STATe] ON.
Note: This command is not needed except for compatibility with ZVR programs. Use
CALCulate<Chn>:MARKer<Mk>:FUNCtion:EXECute to select a search mode and at the same time
initiate the search. The CALCulate<Chn>:MARKer<Mk>:SEARch...,
CALCulate<Chn>:MARKer<Mk>:MAXimum or CALCulate<Chn>:MARKer<Mk>:MINimum functions
also select the search mode.
<Chn>
Channel number used to identify the active trace
<Mk>
Marker number in the range 1 to 10. For a bandfilter search (BFILter) this
numeric suffix is ignored and may be set to any value because the bandfilter
search functions always use markers M 1 to M 4.
Parameters
See list of parameters below
*RST value
–
SCPI,
Command
Types
Device-specific, command or query
The analyzer provides the following search modes:
Mode
Selected search mode
MAXimum
Absolute maximum in the search range (see CALCulate<Chn>:MARKer<Mk>:FUNCtion:DOMain:USER
<numeric_value>)
MINimum
Absolute maximum in the search range
RPEak
Next valid peak to the right of the current marker position
LPEak
Next valid peak to the left
NPEak
Next highest value among the valid peaks
