R&S ZVB - Page 298

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT GUI Reference
Channel Menu
Operating Manual 1145.1084.12 – 30 283
The delay time entered must be zero or positive, so that the trigger event precedes the start of the
measurement (post-trigger).
Remote control:
TRIGger[:SEQuence]:HOLDoff
TRIGger[:SEQuence]:HOLDoff:GENerator<Gen>
TRIGger[:SEQuence]:HOLDoff:MODE
TRIGger[:SEQuence]:HOLDoff:PORT<Pt>
Single (All Chans)
Toggles between single sweep and continuous sweep mode.
 In continuous mode (Single (All Chans) not selected), the analyzer measures continuously,
repeating the current sweep.
 In single sweep mode, the measurement is stopped after the number of sweeps selected in the
Define Restart dialog.
Press Single to activate the single sweep mode and start a single sweep sequence. To start further
sweep sequences press Restart.
Remote control:
INITiate<Ch>:CONTinuous ON | OFF
Restart
Stops the ongoing measurement and restarts a new measurement sequence. In Single sweep mode a
new single sweep sequence is started, according to the Define Restart settings.
It is possible to set all traces to zero when a Restart is executed; see System – System Config –
General – Restart Behavior.
Remote control:
ABORt
INITiate<Ch>[:IMMediate]
Define Restart
Opens a dialog to configure the Single sweep mode.
