ZVT GUI Reference
Channel Menu
Operating Manual 1145.1084.12 – 30 425
settings (including a possible channel calibration) are identical to the previous channel settings; the trace
is created with the trace settings of the former active trace but displayed with another color. The former
and the new active trace are superimposed but can be easily separated, e.g. by changing the Reference
Position.
The new channel is named Ch<n>, where <n> is the largest of all existing channel numbers plus one. The
name can be changed in the Channel Manager.
To create a new trace in the active channel, use the Trace – Traces – Add Trace function. To create a
new channel and a new trace and display it in a new diagram area, use Add Channel + Trace + Diag.
Area.
Remote control:
CONFigure:CHANnel<Ch>[:STATe] ON
CALCulate<Ch>:PARameter:SDEFine "<Trc_name>", "<Parameter>"
DISPlay:WINDow<No>:TRACe:FEED "<Trc_name>"
Add Channel + Trace + Diag. Area
Creates a new channel and a new trace, which is displayed in a new diagram area. The new channel
settings (including a possible channel calibration) are identical to the previous channel settings; the trace
is created with the trace settings of the former active trace but displayed with another color.
The new channel is named Ch<n>, where <n> is the largest of all existing channel numbers plus one. The
name can be changed in the Channel Manager.
To create a new trace in the active channel, use the Trace – Traces – Add Trace function. To create a
new channel and a new trace and display it in the active diagram area, use Add Channel + Trace.
Remote control:
CONFigure:CHANnel<Ch>[:STATe] ON
CALCulate<Ch>:PARameter:SDEFine "<Trc_name>", "<Parameter>"
DISPlay:WINDow<No>:STATe ON
DISPlay:WINDow<No>:TRACe:FEED "<Trc_name>"
Delete Channel
Deletes the active channel including all traces assigned to the channel and removes all display elements
related to the channel from the diagram area. Delete Channel is disabled if the setup contains only one
channel: In manual control, each setup must contain at least one diagram area with one channel and one
trace.
To restore a channel that was unintentionally deleted, use the Undo function.
Remote control:
CONFigure:CHANnel<Ch>[:STATe] OFF
Channel Manager
Opens a dialog to perform the actions in the Channel Select menu systematically and rename channels.
