ZVT Remote Control
Status Reporting System
Operating Manual 1145.1084.12 – 30 601
STATus:QUEStionable:LIMit1<1|2>
The STATus:QUEStionable:LIMit<1|2> registers indicate the result of the limit check. They can be queried
using the commands STATus:QUEStionable:LIMit<1|2>:CONDition? or
STATus:QUEStionable:LIMit<1|2>[:EVENt]? STATus:QUEStionable:LIMit1 is also the summary
register of the lower-level STATus:QUEStionable:LIMit2 register.
The bits in the STATus:QUEStionable:LIMit1 register are defined as follows:
Bit No.
Meaning
0
LIMit2 register summary
This bit is set if a bit is set in the STATus:QUEStionable:LIMit2 register and the associated ENABle bit is set to 1.
1
Failed limit check for trace no. 1
This bit is set if any point on trace no. 1 fails the limit check.
...
...
14
Failed limit check for trace no. 14
This bit is set if any point on trace no. 14 fails the limit check.
The bits in the STATus:QUEStionable:LIMit2 register are defined as follows:
Bit No.
Meaning
0
Not used
1
Failed limit check for trace no. 15
This bit is set if any point on trace no. 15 fails the limit check.
2
Failed limit check for trace no. 16
This bit is set if any point on trace no. 16 fails the limit check.
Numbering of traces
The traces numbers 1 to 16 are assigned as follows:
 Traces assigned to channels with smaller channel numbers have smaller trace numbers.
 Within a channel, the order of traces reflects their creation time: The oldest trace has the smallest,
the newest trace has the largest trace number. This is equivalent to the order of traces in the
response string of the CALCulate<Ch>:PARameter:CATalog? query.
 The number of traces monitored cannot exceed 16. If a setup contains more traces, the newest
traces are not monitored.
STATus:QUEStionable:INTegrity...
The STATus:QUEStionable:INTegrity register monitors hardware failures of the analyzer. It can be
queried using the commands STATus:QUEStionable:INTegrity:CONDition? or
STATus:QUEStionable:INTegrity[:EVENt]? STATus:QUEStionable:INTegrity is also the summary
register of the lower-level STATus:QUEStionable:INTegrity:HARDware register.
