Removes the specified directory.
MMEMory:SETTings:RENorm:MODE AUTO | EXPLicit
Controls the renormalization rules for data export and import globally.
AUTO
The analyzer uses default renormalization rules; refer to the documentation of the
following commands:
MMEMory:STORe:TRACe
MMEMory:STORe:TRACe:CHANnel
MMEMory:STORe:TRACe:PORTs
MMEMory:STORe:TRACe:PORTs:INComplete
MMemory:LOAD:TRACe
MMEMory:LOAD:CKIT:SDATA
MMEMory:LOAD:CORRection:TCOefficient
The MMEMory:SETTings:RENorm:RIMPedance and
MMEMory:SETTings:RENorm:STATe settings are ignored.
EXPLicit
Data export and import according to the
MMEMory:SETTings:RENorm:RIMPedance and
MMEMory:SETTings:RENorm:STATe settings.
*RST value
AUTO
SCPI,
Command
Types
Device-specific, command or query
Example:
*RST; :MMEMory:SETTings:RENorm:MODE EXPLicit; RIMPedance
75.0; STATe ON
Reset the analyzer to create the default trace. Select explicit mode, define a
reference impedance of 75 Ω, and enable renormalization.
MMEMory:STORe:TRACe:PORTs:INComplete 1, 'C:\Program
Files\Rohde&Schwarz\Network Analyzer\Traces\Trc1.s2p',
COMPlex, 1, 2
Store the renormalized trace data to a two-port Touchstone
file. The 75 Ω reference impedance appears in the file
header.
MMEMory:SETTings:RENorm:RIMPedance <impedance>
Defines the target reference impedance for S-matrix export. The value is written into the file header of the
generated Touchstone file. If renormalization is enabled (MMEMory:SETTings:RENorm:STATe ON), it is
also used for renormalization.
This setting is valid in explicit mode only (MMEMory:SETTings:RENorm:MODE EXPLicit).
<impedance>
Real impedance value
*RST value [def. unit]
1 [Ω]
SCPI, Command Types
Device-specific, command or query
