([SENSe<Ch>:]FREQuency:STOP), the stop frequency is set to the start frequency plus the minimum
frequency span ([SENSe<Ch>:]FREQuency:SPAN).
[SENSe<Ch>:]FREQuency:STOP <stop_frequency>
Defines the stop frequency for a frequency sweep which is equal to the right edge of a Cartesian diagram.
<Ch>
Channel number.
<stop_frequency>
Stop frequency of the sweep.
Range [def. unit]
Depending on the instrument model [Hz]. The increment (parameters UP or
DOWN) is 0.1 kHz.
*RST value
Maximum frequency of the analyzer: MAX
SCPI, Command
Types
Confirmed, command or query.
Example:
*RST; :SENS:FREQ:STAR 100000
Activate a frequency sweep and set the start frequency to 100 kHz.
FREQ:STOP 10MHz
Set the stop frequency to 10 MHz.
Note: If the stop frequency entered is smaller than the current start frequency
([SENSe<Ch>:]FREQuency:STARt), the start frequency is set to the stop frequency minus the minimum
frequency span ([SENSe<Ch>:]FREQuency:SPAN).
[SENSe<Ch>:]FREQuency:IMODulation...
This subsystem controls the analyzer's intermodulation measurement mode. Together with the Harmonic
Distortion measurement, the mixer measurement, and the arbitrary configuration of generator and receiver
frequencies (Port Configuration), the intermodulation measurement is included in option R&S ZVA-K4.
[SENSe<Ch>:]FREQuency:IMODulation:COMBiner[:STATe] <Boolean>
Enables or disables the internal combiner
- for network analyzers R&S ZVA connected to an Extension Unit R&S ZVAX24 or R&S ZVAX-TRM with
installed combiner option
- for network analyzers R&S ZVT connected to an Extension Unit R&S ZVAX-TRM with installed combiner
option
- for network analyzers R&S ZVT20 that are equipped with option R&S ZVT20-B11
The internal combiner requires the following port configuration: Lower Tone: Port 1, Upper Tone: Port 3
(see example).
<Ch>
Channel number. If unspecified the numeric suffix is set to 1.
<Boolean>
ON | OFF – enables or disables the measurement using the internal
combiner
*RST value
ON (for <Im> = 3), OFF (for <Im> > 3)
SCPI, Command
Device-specific, command or query.
