This setting is valid for sweep types with equidistant sweep points only. It does not apply to
logarithmic and segmented sweeps.
<Ch>
Channel number.
<step_size>
Stimulus step size.
Range [def.
unit]
Depending on the other channel settings. The minimum step size is equal to the
sweep span divided by the maximum number of points minus one
([SENSe<Ch>:]SWEep:POINts), the maximum step size is equal to the sweep span
([SENSe<Ch>:]FREQuency:SPAN). See also description of manual control and
program example below. [–]
*RST value
Depending on the analyzer model. The default step size is equal to the default
sweep span of the analyzer divided by the default number of points minus one.
SCPI,
Command
Types
Confirmed, with query.
Example:
*RST; :SWE:STEP?
Query the default step size. For a 24 GHz analyzer, the response is 119950000.
119950000 Hz = (24 GHz – 10 MHz) / 200.
SWE:STEP UP
Increase the step size.
FREQ:STOP?; :SWE:POIN?
Query the stop frequency of the sweep and the number of points. Increasing the
step size has changed both values.
[SENSe<Ch>:]SWEep:TIME <duration>
Sets the duration of the sweep (Sweep Time). Setting a duration disables the automatic calculation of the
(minimum) sweep time; see [SENSe<Ch>:]SWEep:TIME:AUTO.
Note: The sweep duration is ignored for the sweep types Time and CW Mode.
<Ch>
Channel number.
<duration>
Duration of the sweep.
Range [def.
unit]
The minimum duration depends on the other channel settings, in particular on the
number of points ([SENSe<Ch>:]SWEep:POINts), the IF bandwidth (BWID) and the
Meas. Delay for each partial measurement ([SENSe<Ch>:]SWEep:DWELl). The
maximum is 100000 s. [s] Changing the duration leaves the number of points
unchanged but directly affects the delay.
*RST value
MIN, depending on the channel settings
SCPI,
Command
Types
Confirmed, command or query
Example:
SWE:TIME 1
Set a total sweep time of 1 s.
SWE:DWEL?
Query the delay for each partial measurement.
