RL78/G1H CHAPTER 7 TIMER ARRAY UNIT

R01UH0575EJ0120 Rev. 1.20 Page 212 of 920

Dec 22, 2016

Figure 7 - 60 Example of Basic Timing of Operation as Delay Counter

Remark 1. m: Unit number (m = 0), n: Channel number (n = 3)

Remark 2. TSmn: Bit n of timer channel start register m (TSm)

TEmn: Bit n of timer channel enable status register m (TEm)

TImn: TImn pin input signal

TCRmn: Timer count register mn (TCRmn)

TDRmn: Timer data register mn (TDRmn)

TEmn

TDRmn

TCRmn

INTTMmn

TImn

TSmn

a + 1 b + 1

FFFFH

0000H
