RL78/G1H CHAPTER 15 SERIAL INTERFACE IICA
R01UH0575EJ0120 Rev. 1.20 Page 445 of 920
Dec 22, 2016
15.3.6 IICA low-level width setting register n (IICWLn)
This register is used to set the low-level width (tLOW) of the SCLAn pin signal that is output by serial interface
IICA and to control the SDAAn pin signal.
The data hold time is decided by value the higher 6 bits of IICWL register.
The IICWLn register can be set by an 8-bit memory manipulation instruction.
Set the IICWLn register while operation of I
2
C is disabled (bit 7 (IICEn) of IICA control register n0 (IICCTLn0) is
0).
Reset signal generation sets this register to FFH.
For details about setting the IICWLn register, see 15.4.2 Setting transfer clock by using IICWLn and IICWHn
registers.
The data hold time is a quarter of the time specified by IICWLn.
Figure 15 - 16 Format of IICA low-level width setting register n (IICWLn)
15.3.7 IICA high-level width setting register n (IICWHn)
This register is used to set the high-level width of the SCLAn pin signal that is output by serial interface IICA and
to control the SDAAn pin signal.
The IICWHn register can be set by an 8-bit memory manipulation instruction.
Set the IICWHn register while operation of I
2
C is disabled (bit 7 (IICEn) of IICA control register n0 (IICCTLn0) is
0).
Reset signal generation sets this register to FFH.
Figure 15 - 17 Format of IICA high-level width setting register n (IICWHn)
Remark 1. For setting procedures of the transfer clock on master side and of the IICWLn and IICWHn registers on slave
side, see
15.4.2 (1) and 15.4.2 (2), respectively.
Remark 2. n = 0, 1
Address: F0232H (IICWL0), F023AH (IICWL1) After reset: FFH R/W
Symbol76543210
IICWLn
Address: F0233H (IICWH0), F023BH (IICWH1) After reset: FFH R/W
Symbol76543210
IICWHn
