RL78/G1H CHAPTER 8 TIMER RJ
R01UH0575EJ0120 Rev. 1.20 Page 227 of 920
Dec 22, 2016
8.3.2 Subsystem clock supply mode control register (OSMC)
The WUTMMCK0 bit can be used to select the timer RJ operation clock.
In addition, by stopping clock functions that are unnecessary, the RTCLPC bit can be used to reduce power
consumption. For details about setting the RTCLPC bit, see CHAPTER 6 CLOCK GENERATOR.
The OSMC register can be set by an 8-bit memory manipulation instruction.
Reset signal generation clears this register to 00H.
Figure 8 - 3 Format of Subsystem clock supply mode control register (OSMC)
Address: F00F3H After reset: 00H R/W
Symbol76543210
OSMCRTCLPC00WUTMMCK00000
WUTMMCK0 Selection of operation clock (f
RTC) for real-time clock, 12-bit interval timer, and timer RJ
0 Subsystem clock (f
SUB)
• The subsystem clock is selected as the operation clock for the real-time clock and the 12-bit interval
timer.
• The low-speed on-chip oscillator cannot be selected as the count source for timer RJ.
1 Low-speed on-chip oscillator clock (f
IL)
• The low-speed on-chip oscillator clock is selected as the operation clock for the real-time clock and the
12-bit interval timer.
• Either the low-speed on-chip oscillator or the subsystem clock can be selected as the count source for
timer RJ.
To Next Page
