RL78/G1H CHAPTER 26 OPTION BYTE
R01UH0575EJ0120 Rev. 1.20 Page 798 of 920
Dec 22, 2016
(3) 000C2H/010C2H
Setting of flash operation mode
• LS (low-speed main) mode
• HS (high-speed main) mode
Setting of the frequency of the high-speed on-chip oscillator
• Select from 1 MHz to 32 MHz.
Caution Set the same value as 000C2H to 010C2H when the boot swap operation is used because
000C2H is replaced by 010C2H.
26.1.2 On-chip debug option byte (000C3H/ 010C3H)
Control of on-chip debug operation
• On-chip debug operation is disabled or enabled.
Handling of data of flash memory in case of failure in on-chip debug security ID authentication
• Data of flash memory is erased or not erased in case of failure in on-chip debug security ID
authentication.
Caution Set the same value as 000C3H to 010C3H when the boot swap operation is used because
000C3H is replaced by 010C3H.
