Renesas RL78/G1H User Manual

RL78/G1H CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120 Rev. 1.20 Page 694 of 920
Dec 22, 2016
18.7.3 Setting for each data rate
The list of each data rate is shown in Table 18 - 51 and the settings required for each data rate is listed in Table
18 - 52 to Table 18 - 59. Set values to addresses listed in Table 18 - 52 to Table 18 - 59 from the left in order
according to the desired data rate in IDLE mode.
Caution Refer to the latest application note for setting data in Table 18 – 52 to Table 18 - 59 when to use
the product.
Table 18 - 51 Each Data Rate List
Frequency
band identifier
PHY
Frequency band
(MHz)
Modulation Mode
Data rate
(kbps)
Modulation
index
Channel
spacing (kHz)
4 863 MHz
(Europe)
863 to 870 2FSK/2GFSK 001 50 1 200
002 100 400
4FSK/4GFSK 003 200 0.33
5 896 MHz
(US)
896 to 901 2FSK/2GFSK 004 10 0.5 25
005 20 50
006 40 100
6 901 MHz
(US)
901 to 902 2FSK/2GFSK 007 10 0.5 25
008 20 50
009 40 100
7 915 MHz
(US)
902 to 928 2FSK/2GFSK 010 50 1 200
011 150 0.5 400
012 200
8 917 MHz
(Korea)
917 to 923.5 2FSK/2GFSK 013 50 1 200
014 150 0.5 400
015 200
9 920 MHz
(Japan)
920 to 928 2FSK/2GFSK 016 50 1 200
000 100 400
017 200 600
4FSK/4GFSK 018 400 0.33
Other 920 to 928 2GFSK 019 300 0.5 600
902 to 928 2GFSK 020 100 0.5 200
902 to 928 2GFSK 021 300 0.5 600
