RL78/G1H CHAPTER 27 FLASH MEMORY

R01UH0575EJ0120 Rev. 1.20 Page 826 of 920

Dec 22, 2016

27.7.2 Register controlling data flash memory

27.7.2.1 Data flash control register (DFLCTL)

This register is used to enable or disable accessing to the data flash.

The DFLCTL register is set by a 1-bit or 8-bit memory manipulation instruction.

Reset input sets this register to 00H.

Figure 27 - 10 Format of Data flash control register (DFLCTL)

Caution Manipulating the DFLCTL register is not possible while rewriting the data flash memory.

Address: F0090H After reset: 00H R/W

Symbol7654321<0>

DFLCTL0000000DFLEN

DFLEN Data flash access control

0 Disables data flash access

1 Enables data flash access

Default Chapter7
